Raspberry Pi 5 Compatible USB-C Power Supply

Sold Out

SKU: VILP_USBCPI5

Specifications

Output:

  • Output voltage: +5.1V DC Minimum load current:
  • 0A Nominal load current: 5.0A Maximum power:
  • 27W Load regulation: ±5%
  • Line regulation: ±2%

  • Ripple & noise: 120mVp-p

  • Rise time: 100ms maximum to regulation limits for
  • DC outputs

  • Turn-on delay: 3000ms maximum at nominal input AC
  • voltage and full load

  • Protection: Short circuit protection
  • Overcurrent protection
  • Over temperature protection

  • Efficiency: 83% minimum (output current from 100%,
    75%, 50%, 25%)

  • 72% minimum at 10% load

  • Output cable:   5 feet  18AWG
  • Output connector: USB Type-C



Input:


Voltage range: 100-240Vac (rated) meaning this would work worldwide with a proper pin converter

96-264Vac (operating) Frequency: 50/60Hz ±3Hz
Current: 0.5A maximum


First, it cranks out a steady +5.1 volts of DC power. Imagine it as the DJ of electricity, always spinning the right voltage tracks. It can handle a load current of 5.0A without breaking a sweat. That's like powering up your gadgets with a turbocharger! And it maxes out at 27W, which is like having a supercharged battery for your devices.

Now, let's talk about regulation – it's the power supply's way of staying in line. It keeps the voltage within ±5% of what it's supposed to be, and the line regulation is even tighter at ±2%. No voltage roller coasters here!

But here's the fun part: it's not all smooth sailing. There's a bit of noise – 120mVp-p, to be precise. It's like the power supply's way of humming along to its own tunes.

When you switch it on, it takes a max of 100ms to hit its groove, and there's a bit of a diva moment with a 3000ms turn-on delay, but that's because it's making sure everything's just right.

The power supply's got your back with protection too. It's like a superhero with short circuit protection, overcurrent protection, and over-temperature protection. It won't let anything bad happen to your precious gadgets.

Now, the efficiency is a solid 83% or more when your device's hunger is at 100%, 75%, 50%, or 25%. It's like a car that gets great gas mileage, but it's still 72% efficient even when it's just idling at 10% load.

Check this out – it comes with a 5-foot cable, the same kind you use to charge your phone, and it has a USB Type-C connector, which is like the modern-day universal plug. So, no more fumbling around with different cables!

Lastly, it's a globetrotter. With a voltage range of 100-240Vac, it can party worldwide with the right pin converter. So, whether you're in New York or New Zealand, it's got you covered. This power supply is like a well-traveled, electric adventurer ready to power your devices wherever you go.

Raspberry Pi 5 Compatible USB-C Power Supply

$13.99

Specifications

Output:

  • Output voltage: +5.1V DC Minimum load current:
  • 0A Nominal load current: 5.0A Maximum power:
  • 27W Load regulation: ±5%
  • Line regulation: ±2%

  • Ripple & noise: 120mVp-p

  • Rise time: 100ms maximum to regulation limits for
  • DC outputs

  • Turn-on delay: 3000ms maximum at nominal input AC
  • voltage and full load

  • Protection: Short circuit protection
  • Overcurrent protection
  • Over temperature protection

  • Efficiency: 83% minimum (output current from 100%,
    75%, 50%, 25%)

  • 72% minimum at 10% load

  • Output cable:   5 feet  18AWG
  • Output connector: USB Type-C



Input:


Voltage range: 100-240Vac (rated) meaning this would work worldwide with a proper pin converter

96-264Vac (operating) Frequency: 50/60Hz ±3Hz
Current: 0.5A maximum


First, it cranks out a steady +5.1 volts of DC power. Imagine it as the DJ of electricity, always spinning the right voltage tracks. It can handle a load current of 5.0A without breaking a sweat. That's like powering up your gadgets with a turbocharger! And it maxes out at 27W, which is like having a supercharged battery for your devices.

Now, let's talk about regulation – it's the power supply's way of staying in line. It keeps the voltage within ±5% of what it's supposed to be, and the line regulation is even tighter at ±2%. No voltage roller coasters here!

But here's the fun part: it's not all smooth sailing. There's a bit of noise – 120mVp-p, to be precise. It's like the power supply's way of humming along to its own tunes.

When you switch it on, it takes a max of 100ms to hit its groove, and there's a bit of a diva moment with a 3000ms turn-on delay, but that's because it's making sure everything's just right.

The power supply's got your back with protection too. It's like a superhero with short circuit protection, overcurrent protection, and over-temperature protection. It won't let anything bad happen to your precious gadgets.

Now, the efficiency is a solid 83% or more when your device's hunger is at 100%, 75%, 50%, or 25%. It's like a car that gets great gas mileage, but it's still 72% efficient even when it's just idling at 10% load.

Check this out – it comes with a 5-foot cable, the same kind you use to charge your phone, and it has a USB Type-C connector, which is like the modern-day universal plug. So, no more fumbling around with different cables!

Lastly, it's a globetrotter. With a voltage range of 100-240Vac, it can party worldwide with the right pin converter. So, whether you're in New York or New Zealand, it's got you covered. This power supply is like a well-traveled, electric adventurer ready to power your devices wherever you go.
