Raspberry Pi Global Shutter Camera
★★★★★
1 review


★★★★★
Raspberry Pi Global Shutter Camera
$50.52
Free shipping
30-day returns
·Authorized Raspberry Pi reseller
-
-
-
Out of stock – check back soon
Order now to receive it in 4 business days
SKU: SC0926
Launched in March 2023 The Raspberry Pi Global Shutter Camera features a 1.5-megapixel Sony IMX296 sensor with integrated global shutter in the same form factor as the existing Raspberry Pi High Quality Camera CS Mount.
It is ideally suited to applications that require accurate imaging in the presence of rapid motion, including sports photography and industrial machine vision.
Specifications:
Form factor: 38 × 38 × 19.8mm (29.5mm adapter and dust cap)
Weight: 34g (41g with adapter and dust cap)
Sensor: Sony IMX296LQR-C
Resolution: 1.58 megapixels (color)
Sensor size: 6.3mm sensor diagonal
Pixel size: 3.45μm × 3.45μm
Output: RAW10
Back focus length of lens: Adjustable (12.5–22.4mm)
Lens standards: CS-Mount, C-Mount (C-CS adapter included)
IR cut filter: Integrated
Ribbon cable length: 150mm
Included accessories: C-CS mount adapter, screwdriver
Tripod mount: 1/4”-20
Full Details, Documents, and Specs are available here
The Global Shutter Camera will accept any CS-mount lens Including this 6mm wide-angle lens & this 16mm telephoto lens
Additional available accessories include:
SKU:
SC0926
EAN:
5056561803234
Description
Launched in March 2023 The Raspberry Pi Global Shutter Camera features a 1.5-megapixel Sony IMX296 sensor with integrated global shutter in the same form factor as the existing Raspberry Pi High Quality Camera CS Mount.
It is ideally suited to applications that require accurate imaging in the presence of rapid motion, including sports photography and industrial machine vision.
Specifications:
Form factor: 38 × 38 × 19.8mm (29.5mm adapter and dust cap)
Weight: 34g (41g with adapter and dust cap)
Sensor: Sony IMX296LQR-C
Resolution: 1.58 megapixels (color)
Sensor size: 6.3mm sensor diagonal
Pixel size: 3.45μm × 3.45μm
Output: RAW10
Back focus length of lens: Adjustable (12.5–22.4mm)
Lens standards: CS-Mount, C-Mount (C-CS adapter included)
IR cut filter: Integrated
Ribbon cable length: 150mm
Included accessories: C-CS mount adapter, screwdriver
Tripod mount: 1/4”-20
Full Details, Documents, and Specs are available here
The Global Shutter Camera will accept any CS-mount lens Including this 6mm wide-angle lens & this 16mm telephoto lens
Additional available accessories include:
SKU:
SC0926
EAN:
5056561803234
